MA152WA-(TX) Real Image MA152WA-(TX) Real Image
Same model may have multiple batches, images only for reference.
MA152WA-(TX) Real Image MA152WA-(TX) Real Image
MA152WA-(TX) Real Image MA152WA-(TX) Real Image
Same model may have multiple batches, images only for reference.

MA152WA-(TX)

Part No MA152WA-(TX)
Manufacturer Panasonic
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY GP 80V 100MA MINI3
Datasheet
MA152WA-(TX) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Diode Configuration 1 Pair Common Anode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 80V
Current - Average Rectified (Io) (per Diode) 100mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.2V @ 100mA
Reverse Recovery Time (trr) 10ns
Current - Reverse Leakage @ Vr 100nA @ 75V
Operating Temperature - Junction 150°C (Max)
Mounting SMD (SMT)
Case / Package Mini3-G1
Win Source Part Number 207220-MA152WA-(TX)
Ultra Librarian 3D Model Ultra Librarian MA152WA-(TX) CAD Model

Description

The MA152WA-(TX) from Panasonic Electronic Components is a pair of common anode diodes that are designed for use in a wide range of applications. They have a maximum voltage of 80V and are designed to provide reliable performance. These diodes have a low reverse leakage current of 100nA at 75V and a forward voltage of 1.2V at 100mA. The MA152WA-(TX) is an excellent choice for use in a wide range of applications.
