EXC-28CH500U Panasonic – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

EXC-28CH500U

Part No EXC-28CH500U
Manufacturer Panasonic
Catalog Common Mode Chokes
Description CMC 160MA 4LN 50 OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Signal Line
Number of Lines 4
Impedance @ Frequency 50 Ohms @ 100 MHz
Current Rating (Max) 160mA
DC Resistance (DCR) (Max) 1.5Ohm
Voltage Rating - DC 5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Size / Dimension 0.079" L x 0.039" W (2.00mm x 1.00mm)
Height (Max) 0.024" (0.60mm)
Case / Package 0804 (2010 Metric), Array, 8 PC Pad
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1527584-EXC-28CH500U
Ultra Librarian 3D Model Ultra Librarian EXC-28CH500U CAD Model

Description

N
