Products specifications Report Issue?

Categories Switches
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Circuit SPST-NO
Switch Function Off-Mom
Contact Rating @ Voltage 0.05A @ 12VDC
Actuator Type Standard
Mounting Surface Mount, Right Angle
Actuator Orientation Side Actuated
Termination Style J Lead
Outline 6.10mm x 4.00mm
Illumination Non-Illuminated
Operating Force 160gf
Switch Travel 0.30mm
Mechanical Life 100,000 Cycles
Temperature Range - Operating -20°C to 70°C
Win Source Part Number 1037276-EVQ-PSD02K
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Audio, Communications & Networking, Consumer Electronics
Family Name EVQPS
Introduction Date December 25, 2001
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Quantity per package 4k pcs
Ultra Librarian 3D Model Ultra Librarian EVQ-PSD02K CAD Model

Description

The Panasonic Electronic Components EVQ-PSD02K is a SPST-NO Off-Mom switch with a contact rating of 0.05A @ 12VDC.

  • Mechanical Life: 100,000 cycles
  • Operating Force: 160gf
  • Mounting Type: surface mount right angled
  • Termination Style: J-lead
  • Actuator Orientation: Side actuated
  • Illuminated: No
  • Outline: 6.10mm x 4.00mm
  • Switch Family: EVQPS
  • Alternative Parts (Cross-Reference): EVQPSC02K and EVQPNF04M
  • Popularity: high
  • Supply and Demand Status: balanced
  • Applications: industrial, audio, communications and networking, and consumer electronics
  • Halogen-Free Compliant: Yes
  • Estimated EOL date: obsolete
