ECK-TFC152MF Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Capacitance 1500pF
Tolerance ±20%
Voltage Rating 250VAC
Temperature Coefficient Y5V (F)
Temperature Range - Operating -25°C to 100°C
Ratings Y2
Applications Safety
Mounting Surface Mount, MLCC
Dimension 0.224" L x 0.177" W (5.70mm x 4.50mm)
Thickness (Max) 0.091" (2.30mm)
Win Source Part Number 109044-ECK-TFC152MF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ECK-TFC152MF CAD Model

Description

Features and Benefits

  • High capacitance stability over temperature
  • Compact size for space-constrained applications
  • Low equivalent series resistance (ESR) for high efficiency

Applications

  • Power management systems
  • Consumer electronics
  • Telecommunication devices

The ECK-TFC152MF is an electronic capacitor designed to provide reliable performance across a wide range of operating conditions. Its compact size makes it an ideal choice for modern electronic designs where space is a premium. Additionally, its low ESR maximizes efficiency, saving energy in critical systems.
