ECC-T3F120JG2 Real Image
Same model may have multiple batches, images only for reference.

ECC-T3F120JG2

Part No ECC-T3F120JG2
Manufacturer Panasonic
Catalog Ceramic Capacitors
Description CAP CER 12PF 3KV SL/GP SMD
Datasheet
ECC-T3F120JG2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Capacitance 12pF
Tolerance ±5%
Voltage Rating 3000V (3kV)
Temperature Coefficient SL/GP
Temperature Range - Operating -25°C to 105°C
Features High Voltage
Applications General Purpose
Mounting Surface Mount, MLCC
Dimension 0.224" L x 0.177" W (5.70mm x 4.50mm)
Thickness (Max) 0.091" (2.30mm)
Win Source Part Number 124063-ECC-T3F120JG2
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ECC-T3F120JG2 CAD Model

Description

Description

The ECC-T3F120JG2 capacitor is designed for applications requiring high reliability and efficiency. It builds on the solid foundation of its predecessor with improved features.

Features and Benefits

  • Enhanced capacitance for greater energy output
  • Improved thermal stability
  • Reduced ESR for increased efficiency
  • Wider operating temperature range

Applications

  • Telecommunications equipment
  • Automotive electronics
  • Home appliances
  • Medical devices

Additional Details

With its advanced features, the ECC-T3F120JG2 is a perfect choice for high-frequency applications requiring consistent performance.
