AXK8L30125BG

Name: AXK8L30125BG
Brand: Panasonic
SKU: 567382
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	AXK8L30125BG
Manufacturer	Panasonic
Catalog	Rectangular Connectors
Description	CONN HDR 30POS SMD GOLD / 30 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Datasheet	AXK8L30125BG Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects - Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr	Panasonic
Series	F4
Package	Tape & Reel
Product Status	Active
Connector Type	Header, Outer Shroud Contacts
Number of Positions	30
Pitch	0.016" (0.40mm)
Number of Rows	2
Mounting Type	Surface Mount
Features	Solder Retention
Contact Finish	Gold
Mated Stacking Heights	0.9mm
Height Above Board	0.025" (0.63mm)
Base Product Number	AXK8L30125
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	567382-AXK8L30125BG
Ultra Librarian 3D Model	Ultra Librarian AXK8L30125BG CAD Model

Description

The AXK8L30125BG is a rectangular connector array from Panasonic's F4 series.

Type: edge-type, mezzanine connector
Connection: board-to-board connections.
Positions: 30
Pitch: 0.016" (0.40mm)
Features: header with outer shroud contacts
Rows: two rows
Contact Finish: gold
Mounting: surface mount technology
Height Above Board: 0.025" (0.63mm)
Package: tape & reel
Standard Package Quantity: 3,000 pcs.
Status: active product
REACH: unaffected by REACH regulations.
