AV36249 Real Image
Same model may have multiple batches, images only for reference.

AV36249

Part No AV36249
Manufacturer Panasonic
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACTION SPDT 3A 125V / Switch Snap Action N.O./N.C. SPDT Hinge Lever 3A 250VAC 125VDC 0.34N Thru-Hole PC Pins Medical
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Switches
Manufacturer Panasonic Electric Works
Series AV3
Packaging Bulk
Circuit SPDT
Switch Function On-Mom
Current Rating 3A (AC/DC)
Voltage Rating - AC 125V
Voltage Rating - DC 30V
Actuator Type Lever, Straight
Mounting Through Hole, Right Angle
Termination Style PC Pin
Operating Force, Torque 35gf
Release Force 3gf
Pretravel 0.110" (2.8mm)
Differential Travel 0.031" (0.8mm)
Overtravel 0.047" (1.2mm)
Operating Position 0.345" (8.8mm)
Mechanical Life 500,000 Cycles
Electrical Life 50,000 Cycles
Operating Temperature Range -25°C ~ 85°C
Win Source Part Number 769361-AV36249
Popularity Medium
Supply and Demand Status Balance
Quantity per package 500
Family Name AV3
Introduction Date August 23, 2002
ECCN EAR99
Ultra Librarian 3D Model Ultra Librarian AV36249 CAD Model

Description

The AV36249 is an electronic switch component manufactured by Panasonic Electric Works.

  • Supply and demand status: balanced
  • Circuit: SPDT
  • Switch function: on-mom
  • Current rating: 3A (AC/DC)
  • Voltage rating - AC: 125V
  • Voltage rating - DC: 30V
  • Mounting: through hole, right angle
  • Termination style: PC pin
  • Operating temperature range: -25°C ~ 85°C
  • Electrical life: 50,000 cycles
  • Mechanical life: 500,000 cycles
  • Actuator type: lever, straight
