ARD1204H Nais(Matsushita Electric Works)
Same model may have multiple batches, images only for reference.

ARD1204H

Part No ARD1204H
Manufacturer Panasonic
Catalog RF Switches
Description IC RF SWITCH SPDT 18GHZ
Datasheet
ARD1204H Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Switches
Mfr Panasonic
Series ARD
Package Bulk
Product Status Active
RF Type General Purpose
Topology Reflective
Circuit SPDT
Frequency Range 0Hz ~ 18GHz
Isolation 60dB (min)
Insertion Loss 0.5dB (max)
Test Frequency 18GHz
Impedance 50Ohm
Voltage - Supply 4.5V
Temperature Range - Operating -55°C ~ 85°C
Package / Case Module, Pin Contacts
Base Product Number ARD1204
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.49.0055
Win Source Part Number 564504-ARD1204H
Ultra Librarian 3D Model Ultra Librarian ARD1204H CAD Model

Description

The ARD1204H is an RF switch from Panasonic's ARD series. ARD1204H, manufactured by Panasonic, is designed for RF and wireless applications, specifically in the frequency range of 0Hz to 18GHz.

  • Series: ARD
  • Frequency Range: 0Hz to 18GHz
  • Insertion Loss (Max): 0.5dB
  • Isolation (Min): 60dB
  • Switch Configuration: SPDT
  • Switch Type: Reflective
  • Impedance: 50Ohm
  • Operating Temperature: -55°C to 85°C
  • Package: Bulk
  • Voltage Supply: 4.5V
  • Contacts: Pin
