AQZ102D Nais(Matsushita Electric Works)
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQZ
Package Tube
Product Status Active
Mounting Type Through Hole
Circuit SPST-NO (1 Form A)
Output Type DC
Voltage - Input 1.4VDC
Voltage - Load 0 V ~ 60 V
Load Current 3.6 A
On-State Resistance (Max) 90 mOhms
Termination Style PC Pin
Package / Case 4-SIP
Supplier Device Package 4-SIL
Base Product Number AQZ102
Standard Package 25 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 564487-AQZ102D
Ultra Librarian 3D Model Ultra Librarian AQZ102D CAD Model

Description

The PhotoMOS AQZ102D is a solid state relay designed for high-performance applications from Panasonic.

  • Termination Style: PC pin
  • Package: Through-hole
  • Voltage Input: 1.4VDC
  • Output Type: DC
  • Circuit Configuration: SPST-NO (1 Form A)
  • Maximum On-State Resistance: 90 mOhms
  • Load Current: 3.6 A
  • Voltage Load Range: 0V to 60V
  • Suitable for: Industrial controls, automotive systems, and power supplies
