AQY212GS

Part No AQY212GS
Manufacturer Panasonic
Catalog Solid State Relays
Description SSR RELAY SPST-NO 1A 0-60V / Solid State SPST-NO (1 Form A) 4-SOP (0.173", 4.40mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQY
Package Tube
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.32VDC
Voltage - Load 0 V ~ 60 V
Load Current 1 A
On-State Resistance (Max) 700 mOhms
Termination Style Gull Wing
Package / Case 4-SOP (0.173", 4.40mm)
Supplier Device Package 4-SOP
Base Product Number AQY212
Standard Package 100 pcs
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 564447-AQY212GS
Ultra Librarian 3D Model Ultra Librarian AQY212GS CAD Model

Description

AQY212GS from Panasonic is a solid state relay designed for designers who need compact, low-maintenance switching in control and interface circuits. In applications such as industrial I/O, test equipment, communications hardware, security systems, and embedded control boards, solid state relays like this are often selected for silent operation, electrical isolation, and long service life compared with mechanical relay alternatives. Panasonic is widely recognized in this category, making AQY212GS a practical option for engineers evaluating reliable signal or load switching solutions in space-constrained assemblies. For ongoing designs, the current lifecycle status is information not available, so teams should confirm availability and long-term support directly with Panasonic or authorized sources before committing to production. RoHS compliance information is also not available in the provided data and should be verified through the latest datasheet, compliance certificate, or manufacturer declaration before procurement for regulated markets.
