AN26018A-NL Panasonic AN26018A-NL Real Image AN26018A-NL real image
Same model may have multiple batches, images only for reference.
AN26018A-NL Panasonic AN26018A-NL Real Image AN26018A-NL real image
AN26018A-NL Panasonic AN26018A-NL Real Image AN26018A-NL real image
Same model may have multiple batches, images only for reference.

AN26018A-NL

Part No AN26018A-NL
Manufacturer Panasonic
Catalog RF Amplifiers
Description IC LNA UHF BAND DTV 5-SMINI
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Frequency 400MHz to 800MHz
P1dB -5dBm
Gain 14.5dB
Noise Figure 1.5dB
RF Type UHF
Supply Voltage - Operating 2.7 V to 3 V
Operating Supply Current 3mA
Test Frequency 470MHz
Case / Package SSMINI-5DC
Win Source Part Number 1016696-AN26018A-NL
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AN26018A-NL CAD Model

Description

The Panasonic Electronic Components 1016696-AN26018A-NL is a UHF RF/IF and RFID electronic component with a test frequency of 470MHz and a frequency range of 400MHz to 800MHz.

  • Component Type: RF/IF and RFID
  • Test Frequency: 470MHz
  • Frequency Range: 400MHz to 800MHz
  • Gain: 14.5dB
  • Noise Figure: 1.5dB
  • P1dB: -5dBm
  • Package: SSMINI-5DC
  • Operating Supply Voltage: 2.7V to 3V
  • Operating Supply Current: 3mA
  • Supply and Demand Status: Sufficient
  • Packaging: Reel - TR
