The STK681-320GEVB, from ON Semiconductor, is a comprehensive evaluation board designed specifically for the STK681-320, a unipolar constant-current motor driver. This evaluation board provides an excellent platform for engineers and designers to explore the capabilities and features of the STK681-320 motor driver in a wide range of motor driving applications.

The STK681-320GEVB is equipped with a built-in micro-stepping controller and is capable of driving a unipolar stepper motor. It operates on a supply voltage ranging from 8.5V to 44V, which allows for flexibility in various application requirements. The board is capable of delivering an output current of up to 1.5A, making it suitable for driving small to medium-sized stepper motors commonly used in office automation machines, surveillance cameras, and small industrial equipment.

Key Features:

• Integrated micro-stepping controller for precise motor control.
• Wide operating voltage range (8.5V to 44V) to accommodate different motor specifications.
• High output current capability (up to 1.5A) for driving a range of unipolar stepper motors.
• Thermal shutdown and overcurrent protection features for enhanced safety and reliability.
• Easy-to-use evaluation board for quick setup and testing.
• LED indicators for visual feedback on motor driver status.
• DIP switches for easy micro-stepping configuration and control mode selection.

The evaluation board also comes with multiple protection features, such as thermal shutdown and overcurrent protection, which help to prevent damage to the board and the motor under extreme conditions. Additionally, the STK681-320GEVB includes LED indicators that provide visual feedback on the status of the motor driver operations, which is invaluable for debugging and development purposes.

With its user-friendly interface, including DIP switches for straightforward micro-stepping and control mode adjustments, the STK681-320GEVB is an ideal choice for rapid prototyping and testing of motor control solutions. Whether it's for educational purposes, hobby projects, or professional industrial applications, the STK681-320GEVB from ON Semiconductor offers a versatile and reliable platform for unipolar stepper motor control.
