The NUP4004M5T1G from ON Semiconductor is a cutting-edge, multi-line transient voltage suppressor array designed to protect high-speed data lines from electrostatic discharge (ESD), cable discharge events (CDE), electrical fast transients (EFT), and lightning-induced surge currents. This robust component is tailored for applications where the safeguarding of sensitive electronics from voltage spikes is critical.

Key Features

• ESD Protection: It offers superb ESD protection for high-speed data lines, exceeding IEC61000-4-2 (ESD) standard, with ±15kV (air discharge) and ±8kV (contact discharge) protection.
• Low Capacitance: The device features low line capacitance, typically 0.65 pF, making it ideal for protecting high-speed data lines without compromising signal integrity.
• Low Clamping Voltage: With its low clamping voltage, the NUP4004M5T1G ensures that the protected components will not be subjected to high voltage stress during transient conditions.
• Multi-Line Protection: This component can protect up to four data or power lines simultaneously, providing a compact and efficient solution for modern electronic devices.
• SC−88 Package: The small SC−88 (SOT−353) package allows for space-saving PCB design, which is crucial in portable electronic devices where space is at a premium.

Applications

The NUP4004M5T1G is versatile and can be used in a variety of applications, including:

• USB 1.1/2.0 Power and Data Line Protection
• Mobile Handsets and Accessories
• Portable Electronics
• Serial and Parallel Ports
• Notebooks, Desktops, and Servers
• MP3 Players
• Digital Cameras and Video Cameras

Quality and Reliability

ON Semiconductor is renowned for its commitment to quality and reliability, and the NUP4004M5T1G is no exception. This product is manufactured in ISO/TS16949, ISO9001, and ISO14001 certified facilities, ensuring that every component meets the highest standards of performance and durability.
