ON Semiconductor NUP2201MR6T1G - ESD Protection Diode

The NUP2201MR6T1G from ON Semiconductor is a state-of-the-art ESD protection diode designed to safeguard high-speed data lines and I/O ports from electrostatic discharge (ESD) and other voltage-induced transient events. This robust component is a must-have for any circuit where data integrity and component longevity are of paramount importance.

Key Features

• Bi-directional ESD protection: The NUP2201MR6T1G provides symmetrical ESD protection for data lines, ensuring that both positive and negative transient voltages are effectively clamped.
• Low Capacitance: With a low loading capacitance of typically 10 pF, this device is ideal for protecting high-speed data lines without significantly affecting signal integrity.
• Stand-off Voltage: It offers a stand-off voltage of 5.5V, making it suitable for a wide range of applications.
• Peak Power Dissipation: The device is capable of withstanding peak pulse power of 250W (8/20μs waveform), providing robust protection against high energy transients.
• Small Package: Enclosed in a SOT−23 package, the NUP2201MR6T1G is compact and suitable for high-density circuit board designs.
• AEC−Q101 Qualified: This component meets the stringent requirements of the Automotive Electronics Council, making it suitable for automotive applications.
• ISO 7637 Compatible: Compatibility with ISO 7637 standards ensures that the device can handle the electrical disturbances related to road vehicles.

Applications

The NUP2201MR6T1G is versatile and can be used in a variety of applications, including but not limited to:

• USB 1.1/2.0 Power and Data Line Protection
• Monitors and Flat Panel Displays
• Cellular Handsets and Accessories
• Notebook Computers
• Portable Electronics
• Serial and Parallel Ports

With its combination of low capacitance, high ESD immunity, and a small form factor, the NUP2201MR6T1G is an excellent choice for protecting sensitive electronic components in any application where ESD protection is critical. ON Semiconductor's commitment to quality ensures that this ESD protection diode will enhance the reliability and longevity of your electronic devices.
