The NLX2G04AMUTCG from ON Semiconductor is a high-performance, dual inverter gate designed to meet the requirements of a wide range of applications. This advanced logic gate is part of ON Semiconductor's extensive portfolio of semiconductor solutions, known for their reliability and efficiency.

Key Features

• Configuration: The device contains two independent inverters, allowing for flexible circuit designs.
• Operating Voltage: It operates at a voltage range of 1.65V to 5.5V, making it suitable for low-voltage and battery-powered applications.
• Logic Level Translation: Its broad voltage range also enables it to perform logic level translation between different operating voltages within a system.
• High-Speed Operation: With a propagation delay time of approximately 3.7ns at 5V, it provides high-speed operation, which is critical for modern digital circuits.
• Low Power Consumption: The device has been optimized for low power consumption, contributing to energy-efficient designs.
• Output Drive Capability: It can drive up to 8mA at 5V, allowing it to control a variety of output loads.
• Mounting Type: The NLX2G04AMUTCG comes in a micro-lead frame (MLF) package, specifically in a 6-UDFN (1.45x1.0) package, which is ideal for space-constrained applications.
• Temperature Range: It is designed to operate within a temperature range of -55°C to 125°C, ensuring stability and performance under extreme conditions.

Applications

The dual inverter gate is suitable for a variety of applications, including:

• Logic level shifting
• Signal inversion
• Oscillator circuits
• Wave shaping
• Glitch removal
• High-speed digital circuits

With its compact form factor, low power consumption, and high-speed operation, the NLX2G04AMUTCG is an excellent choice for designers looking to create efficient and reliable digital systems. ON Semiconductor's commitment to quality ensures that this dual inverter gate will provide superior performance for your electronic designs.
