The NCP1083QBCGEVB is a versatile and powerful evaluation board from ON Semiconductor designed to showcase the capabilities of the NCP1083, a high-performance Power over Ethernet (PoE) Powered Device (PD) controller that integrates a PoE interface and a DC-DC converter. This evaluation board is an essential tool for engineers and developers who are looking to implement PoE solutions in their applications, such as IP cameras, wireless access points, and VoIP phones.

Key Features

• Supports the IEEE 802.3af and IEEE 802.3at PoE standards for compatibility with a wide range of PoE sources.
• Integrated DC-DC converter with adjustable output voltage, enabling the board to power a variety of devices.
• Signature resistor and classification capabilities for communication with Power Sourcing Equipment (PSE).
• Over-temperature, over-current, and under-voltage lockout protection for safe and reliable operation.
• Compact and robust design for easy integration into existing systems or for use in prototyping new designs.

Benefits

The NCP1083QBCGEVB evaluation board simplifies the process of evaluating the NCP1083 controller. Its plug-and-play nature allows for immediate operation once connected to a PoE network, reducing development time and accelerating the product design cycle. With its built-in protection features, the board ensures that the connected devices are safeguarded against potential damage from electrical anomalies.

Applications

With its high level of integration and compliance with PoE standards, the NCP1083QBCGEVB is suitable for a broad range of applications. It is an ideal solution for powering devices in remote locations where traditional power sources are impractical or unavailable. The evaluation board is also an excellent educational tool for those looking to learn more about PoE technology and its applications in modern networking environments.

Getting Started

The evaluation board comes with comprehensive documentation, including a user manual, schematic diagrams, and application notes to assist users in getting started quickly. ON Semiconductor also provides technical support and design resources to help with any aspect of using the NCP1083QBCGEVB evaluation board.
