ON Semiconductor MMSZ5236BT1 Zener Diode

The MMSZ5236BT1 from ON Semiconductor is a high-quality Zener diode, designed to provide excellent voltage regulation with a minimal footprint. This surface-mount device comes in a compact SOD-123 package, making it suitable for high-density circuit board designs. The MMSZ5236BT1 is a popular choice among engineers and designers for its reliability and consistent performance in voltage regulation and protection applications.

Product Features:

• Voltage Range: This Zener diode offers a nominal Zener voltage of 7.5V, which makes it suitable for a variety of electronic circuits that require a precise voltage reference or regulation at this voltage level.
• Power Dissipation: With a power dissipation of 500 mW, the MMSZ5236BT1 can handle a moderate amount of power, making it adequate for many low-power applications.
• Tolerance: The Zener voltage tolerance is ±5%, ensuring accurate voltage regulation and stable operation in your electronic designs.
• Thermal Characteristics: The device operates efficiently over a wide temperature range of -55°C to +150°C, which makes it suitable for use in various environmental conditions.
• Package: The SOD-123 package is not only compact but also offers a low profile, which is essential for today's slim and densely packed electronic devices.

Applications:

The MMSZ5236BT1 is versatile and can be used in a broad range of applications, such as:

• Voltage regulation modules
• Overvoltage and surge protection circuits
• Power management systems
• Consumer electronics
• Telecommunication devices

ON Semiconductor's commitment to quality ensures that the MMSZ5236BT1 Zener diode is a reliable component for your circuit protection and regulation needs. Whether you are designing power supplies, or looking to integrate a stable voltage reference into your product, the MMSZ5236BT1 is a solid choice that combines performance with a small footprint.

For detailed specifications and application notes, it is recommended to consult the official datasheet and technical documentation provided by ON Semiconductor.
