ON Semiconductor MC74ACT541DWG Octal Buffer/Line Driver

The MC74ACT541DWG is a high-performance, octal buffer and line driver designed to interface with 8-bit microprocessors and drive bus lines or buffer memory address registers. Manufactured by ON Semiconductor, a leading innovator in energy-efficient electronics, this integrated circuit is part of the ACT family, which utilizes advanced CMOS technology to achieve high-speed operation while maintaining CMOS low power dissipation.

Key Features

• Logic Type: Octal Buffer/Line Driver with 3-State Outputs
• Number of Channels: 8
• Output Type: 3-State
• Input Level: CMOS
• Output Level: CMOS
• Supply Voltage Range: 4.5V to 5.5V
• Operating Temperature Range: -40°C to +85°C
• Package / Case: SOIC-20W

This device features inputs and outputs on opposite sides of the package to facilitate printed circuit board layout. The MC74ACT541DWG is designed for asynchronous communication between data buses. The control function implementation minimizes external timing requirements.

Performance Benefits

The outputs can be put in a high-impedance state to serve as both data receiving and data transmitting to and from the bus lines. This high-impedance state ensures that the outputs neither load the bus when they are not actively driving it, nor do they interfere with other drivers that might.

With its fast propagation delays and reduced power consumption, this device is ideal for a variety of applications including personal computers, workstations, and high-speed data transfer systems.

Quality and Reliability

ON Semiconductor's commitment to quality ensures that the MC74ACT541DWG meets stringent standards for performance and reliability. The device is available in a wide-body SOIC-20 package, which is lead-free and RoHS compliant, making it suitable for eco-friendly manufacturing processes.

Whether you're developing high-speed data interfaces or expanding the number of outputs for your microprocessor, the MC74ACT541DWG provides a reliable and efficient solution that you can trust to keep your systems running smoothly.
