ON Semiconductor MBRB20100CTT4G Overview

The MBRB20100CTT4G is a high-performance Schottky rectifier from ON Semiconductor, designed to cater to a wide range of power applications. This component is well-suited for use in power supply circuits, offering efficient and reliable operation. The MBRB20100CTT4G is housed in a D2PAK surface-mount package, which not only saves space on the PCB but also ensures improved thermal performance and power handling capabilities.

Key Features

• High Forward Surge Capability: This device is capable of handling high surge currents, making it ideal for applications that may experience occasional surges or spikes in power demand.
• Low Power Loss/High Efficiency: The low forward voltage drop and high efficiency of the MBRB20100CTT4G make it an energy-saving choice for modern electronic applications.
• High Junction Temperature Capability: With a maximum operating junction temperature of 150°C, this Schottky rectifier can withstand high temperature environments, ensuring reliability and longevity of the end product.
• Guard-Ring for Stress Protection: The inclusion of a guard-ring enhances the device's ruggedness and long-term reliability by providing protection against voltage spikes and other stress factors.
• Pb-Free Package: The MBRB20100CTT4G is available in a lead-free package, making it suitable for use in environmentally-sensitive applications and complying with current RoHS regulations.

Applications

ON Semiconductor's MBRB20100CTT4G is versatile and can be used in a variety of applications, including:

• Switching power supplies
• Converters
• Free-wheeling diodes
• Reverse battery protection
• Automotive applications
• Power management in portable devices

Technical Specifications

The MBRB20100CTT4G boasts a 200V reverse voltage rating and a 20A average rectified forward current. It also features a peak repetitive reverse voltage (Vrrm) of 200V and a maximum forward voltage drop (Vf) of 0.83V at 10A. This Schottky rectifier is a testament to ON Semiconductor's commitment to providing high-quality, robust power management solutions.

Whether you are designing a power supply for consumer electronics or industrial systems, the MBRB20100CTT4G from ON Semiconductor is a reliable and efficient choice that ensures your application runs smoothly.
