Product Overview: M74VHC1G132DTT1G by ON Semiconductor

The M74VHC1G132DTT1G is a high-performance CMOS single 2-input NAND Schmitt trigger designed and manufactured by ON Semiconductor, a leader in energy-efficient innovations. This logic gate device is part of the VHC family, which is known for its low power consumption and high noise immunity equivalent to JEDEC standard no. 17A. It is the ideal choice for interfacing with high-speed TTL logic in mixed 3.3V/5V systems.

Key Features

• Advanced High-Speed CMOS Technology: The M74VHC1G132DTT1G is built using advanced high-speed CMOS technology, ensuring rapid response times and high-speed operation without compromising on power efficiency.
• Power Down Protection: The device is equipped with power down protection on inputs and outputs, offering enhanced durability and reliability, especially in unpredictable power environments.
• Low Power Dissipation: With a low power dissipation of ICC = 2µA (max.) at TA = 25°C, this product offers an energy-efficient solution for modern electronic applications.
• High Noise Immunity: The VHC logic family boasts a VNIH = VNIL = 28% VCC (min.) noise immunity, ensuring stable performance even in electrically noisy environments.
• Compatibility: The M74VHC1G132DTT1G is designed to be compatible with TTL output levels, making it versatile for use in various applications that require high-speed logic interfacing.

Applications

The versatility of the M74VHC1G132DTT1G makes it suitable for a wide range of applications, including:

• Wave and pulse shapers
• High-speed logic circuits
• Communication systems
• Data processing
• Control systems

Package and Quality Assurance

The M74VHC1G132DTT1G is available in a small TSSOP-5 package, providing a compact solution for space-constrained applications. ON Semiconductor is committed to the highest standards of quality and reliability, and this product is rigorously tested to ensure performance and durability.

With its combination of high-speed operation, low power consumption, and robust noise immunity, the M74VHC1G132DTT1G from ON Semiconductor stands out as a superior choice for designers looking for a reliable and efficient NAND Schmitt trigger logic gate.
