ON Semiconductor LB1836M-TLM-E Motor Driver IC

The LB1836M-TLM-E from ON Semiconductor is a high-performance motor driver IC designed to cater to the precise control requirements of small and low-voltage motors. This versatile driver is an ideal solution for a wide range of applications, from office automation equipment to battery-powered devices, thanks to its efficient design and low power consumption.

Key Features

• Motor Type Compatibility: The LB1836M-TLM-E is suitable for driving small DC motors and stepper motors, providing flexibility in application use.
• Operating Voltage Range: It operates within a voltage range of 2.5V to 9V, making it perfect for low-voltage applications and portable devices.
• Output Current: The device can deliver an output current of up to 400 mA, ensuring sufficient power for a broad range of motor operations.
• Low Saturation Voltage: The IC features a low saturation voltage, which contributes to reduced power loss and improved energy efficiency during operation.
• Dual H-Bridge: Equipped with a dual H-Bridge, the LB1836M-TLM-E can control two DC motors or one stepper motor, offering bidirectional drive.

Advanced Protection Features

• Thermal Shutdown Circuit: This built-in feature protects the IC from overheating, ensuring long-term reliability and safety in operation.
• Low Voltage Malfunction Prevention: The motor driver is designed to prevent malfunction when the supply voltage drops, thus safeguarding the connected motors.

Package and Mounting

The LB1836M-TLM-E comes in a compact SOP package, which is conducive to space-saving designs. Its surface-mount technology (SMT) allows for efficient assembly and integration into various electronic circuits. The small form factor combined with the low profile of the package makes it an excellent choice for sleek, modern applications.

Applications

With its robust design and versatile features, the LB1836M-TLM-E is well-suited for a variety of applications, including but not limited to:

• Portable devices
• Battery-powered toys
• Office automation machines
• Small home appliances

In summary, the ON Semiconductor LB1836M-TLM-E motor driver IC combines efficiency, versatility, and protection features to deliver superior performance for driving small motors across a spectrum of low-voltage applications.
