Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Bipolar
Applications Fan Motor Driver
Output Current 800mA
Supply Voltage - Operating 3.8 V to 16.8 V
Voltage - Load 3.8 V to 16.8 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 10-SOIC
Win Source Part Number 1021341-LB11862MC-AH
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LB11862MC-AH CAD Model

Description

Introducing the LB11862MC-AH Motor Driver from ON Semiconductor

The LB11862MC-AH from ON Semiconductor is a highly efficient, three-phase motor driver designed to cater to a wide range of applications that require precision motor control. This compact, yet powerful integrated circuit (IC) is an ideal solution for designers looking to enhance performance in their motor-driven systems.

Key Features

  • Three-Phase Brushless Motor Control: The LB11862MC-AH is capable of driving three-phase brushless DC motors, providing smooth and efficient operation.
  • Low Voltage Operation: Designed for low voltage applications, this motor driver operates effectively within a voltage range, making it versatile for various portable and battery-powered devices.
  • Integrated Hall Sensor Inputs: The IC includes built-in Hall sensor inputs, which are essential for rotor position detection, ensuring precise motor control and synchronization.
  • High Output Current: With its ability to deliver high output current, the LB11862MC-AH can drive motors with considerable power, despite its small footprint.
  • Overcurrent Protection: The built-in overcurrent protection feature safeguards the motor and the driver from potential damage caused by excessive current.
  • Thermal Shutdown Feature: The thermal shutdown circuitry prevents the IC from overheating, enhancing the longevity and reliability of both the motor and the driver.

Applications

The LB11862MC-AH is suitable for a variety of applications where efficient and reliable motor control is paramount. Its typical use cases include:

  • Fans and blowers in consumer electronics
  • Small cooling units for computers and servers
  • Battery-powered tools
  • Home appliances
  • Drones and other small electric vehicles

Compact and Reliable

ON Semiconductor's commitment to quality and performance is evident in the LB11862MC-AH motor driver. The device's compact size makes it an excellent choice for space-constrained applications while delivering the reliability and functionality that ON Semiconductor is known for. With its advanced features, this motor driver stands out as a superior choice for designers looking to improve their motor control systems.

Choose the LB11862MC-AH for your next project to experience the perfect blend of efficiency, reliability, and performance in motor control technology.
