ON Semiconductor H11C2 Optocoupler

The H11C2 from ON Semiconductor is a high-performance optocoupler that provides electrical isolation between its input and output circuits. This component is designed for applications requiring high-voltage insulation, fast switching, and low-power consumption. It is a versatile device suitable for a variety of uses, including signal transmission between systems of different potentials and impedances, system ground isolation, and protection from high voltage spikes.

Key Features

• High Isolation Voltage: The H11C2 offers an impressive isolation voltage of 5300 VRMS, providing excellent protection against high-voltage transients and ensuring the safety of sensitive electronic circuits.
• High-Speed Switching: With a typical rise time of only 2µs and a fall time of 2.5µs, this optocoupler is capable of high-speed operation, making it suitable for applications that require fast signal transfer.
• Low Input Current: The device operates with a low input current, ensuring energy efficiency and compatibility with digital logic levels.
• Industry Standard 6-Pin DIP Package: The H11C2 comes in a standard dual-in-line package, which is easy to handle and integrate into a wide range of electronic systems.

Applications

The H11C2 optocoupler is ideal for use in:

• DC motor controllers
• Telecommunication equipment
• Industrial systems
• Power supply management
• PLC interfaces

Reliability and Quality

ON Semiconductor is known for its commitment to quality, and the H11C2 is no exception. It undergoes rigorous testing to ensure it meets the highest standards of reliability and performance. Whether used in a professional or hobbyist setting, the H11C2 is a dependable choice for providing electrical isolation while maintaining signal integrity.

Technical Specifications

Parameter Value Isolation Voltage 5300 VRMS Input-Output Isolation Voltage 7500 VPK Current Transfer Ratio 20% to 300% Input Forward Voltage 1.5 V (Typical) Output Collector-Emitter Voltage 30 V Output Collector Current 50 mA
