The CM1693-04DE by ON Semiconductor is a cutting-edge EMI (Electromagnetic Interference) filtering and signal conditioning component designed to enhance system performance by mitigating unwanted noise and preserving signal integrity in electronic devices. This compact and efficient solution is ideal for a wide range of applications, including mobile phones, personal computers, and other sensitive electronic equipment.

Key Features

• Integrated ESD Protection: The CM1693-04DE offers excellent electrostatic discharge (ESD) protection, ensuring that the device is safeguarded against sudden electrical surges that can cause significant damage to electronic components.
• Low Pass Filter Design: With its low pass filter architecture, this component effectively filters out high-frequency noise, allowing only signals with frequencies below the cutoff frequency to pass through, which is crucial for maintaining signal clarity and preventing data corruption.
• Low Insertion Loss: The device is engineered to have minimal insertion loss, which means it does not significantly attenuate the signal as it passes through the filter, thereby preserving the signal strength and quality.
• High Attenuation: It offers high attenuation of above 30 dB at 800 MHz, which is particularly beneficial for blocking unwanted high-frequency signals and preventing interference with the device's operation.

Applications

• Mobile and Cordless Phones
• Data Lines for Personal Computers
• Peripheral Ports and Interfaces
• Network Servers and Telecom Infrastructure

Technical Specifications

The CM1693-04DE is packaged in a compact, lead-free, 6-pin UDFN package with a nominal impedance of 100 ohms. It operates over a wide temperature range, ensuring reliable performance under varying environmental conditions. The device's low clamping voltage and fast response time to ESD strikes make it an optimal choice for protecting sensitive circuits from both conducted and radiated ESD threats.

Conclusion

ON Semiconductor's CM1693-04DE is a robust EMI filtering and signal conditioning solution that offers a blend of protection, performance, and reliability. Its ability to filter out noise and protect against ESD makes it a smart choice for designers looking to enhance the resilience and functionality of their electronic systems.
