The Omron XG4E-1072 is a high-quality, robust header connector designed for secure and reliable connections in various electronic applications. This connector is a critical component in connecting flat cables to PCBs (printed circuit boards) and other devices, ensuring efficient signal transmission and power delivery.

Applications

• Industrial Automation: Used in PLCs (Programmable Logic Controllers), HMIs (Human Machine Interfaces), and other industrial control systems for signal and power connections.
• Robotics: Employed in robotic arms and control systems to connect sensors, actuators, and other peripheral devices.
• Medical Equipment: Integrated into diagnostic and monitoring devices, ensuring reliable data transmission.
• Test and Measurement Instruments: Used in oscilloscopes, signal generators, and other testing equipment for connecting probes and signal sources.
• Telecommunications: Utilized in communication equipment such as routers, switches, and modems for interconnecting various modules.

Features

• 10-Pin Configuration: Provides a 10-pin interface for connecting flat cables with a corresponding socket connector.
• Through-Hole Mounting: Designed for secure mounting onto PCBs via through-hole soldering.
• Polarization Key: Features a polarization key to prevent incorrect mating and ensure proper alignment.
• Durable Construction: Made from high-quality materials to withstand mechanical stress and environmental factors.
• High Contact Reliability: Ensures stable and consistent electrical connections.

Benefits

• Secure Connection: Provides a robust and reliable connection, minimizing signal loss and ensuring data integrity.
• Easy Installation: Through-hole mounting simplifies the installation process.
• Prevents Misconnections: Polarization key ensures correct mating, avoiding potential damage to the equipment.
• Long-Term Reliability: Durable construction ensures long-term performance and reduces the need for frequent replacements.
• Versatile Application: Suitable for a wide range of applications across various industries.

Additional Details

The XG4E-1072 header connector is designed for use with standard 2.54mm pitch flat cables. It is typically made from high-temperature thermoplastic materials that can withstand soldering processes. The connector’s pins are often gold-plated to provide excellent electrical conductivity and resistance to corrosion. It conforms to industry standards such as RoHS, ensuring compliance with environmental regulations.

The connector's design includes features to improve solderability, such as wide soldering pads and pin configurations that facilitate solder flow. Its compact size allows for high-density mounting on PCBs, making it suitable for space-constrained applications. The connector’s operating temperature range is typically specified to ensure reliable performance in various environmental conditions. Its mechanical strength is designed to withstand the stresses associated with cable mating and unmating operations.
