SSG-01T-5 Real Image
Same model may have multiple batches, images only for reference.

SSG-01T-5

Part No SSG-01T-5
Manufacturer Omron
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACT SPDT 100MA 125V / Switch SPDT Chassis Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Limit Switches
Mfr Omron Electronics Inc-EMC Div
Series SSG
Package Bulk
Circuit SPDT
Switch Function On-Mom
Current Rating (Amps) 100mA (AC/DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 30 V
Actuator Type Round (Pin Plunger)
Mounting Type Chassis Mount
Termination Style Quick Connect - 0.110" (2.8mm)
Ingress Protection IP40
Operating Force 51gf
Release Force 4.079gf
Pretravel 0.024" (0.6mm)
Differential Travel 0.004" (0.1mm)
Overtravel 0.015" (0.4mm)
Temperature Range - Operating -25°C ~ 125°C
Operating Position 0.330" (8.4mm)
Electrical Life 200,000 Cycles
Mechanical Life 10,000,000 Cycles
Base Product Number SSG-01
Other Names SSG01T5
Standard Package 100
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.7000
Win Source Part Number 1233454-SSG-01T-5
Ultra Librarian 3D Model Ultra Librarian SSG-01T-5 CAD Model

Description

The Omron Electronics Inc-EMC Div SSG-01T-5 is a SPDT limit switch with a quick connect termination style of 0.110" (2.8mm).

  • Circuit: SPDT
  • Termination Style: Quick connect 0.110" (2.8mm)
  • Ingress Protection: IP40
  • Voltage Rating: 125V (AC) and 30V (DC)
  • Operating Force: 51gf
  • Mechanical Life: 10,000,000 cycles
  • Differential Travel: 0.004" (0.1mm)
  • Overtravel: 0.015" (0.4mm)
  • Temperature Range: -25°C to 125°C
  • Current Rating: 100mA (AC/DC)
  • Packaging: Bulk
  • Popularity: medium
