The MSM514265E-60T3-K is a 262,144-word x 4-bit Dynamic RAM (DRAM) manufactured by OKI/Metcal. It features fast access times, making it suitable for various applications requiring temporary data storage with quick read and write capabilities.

Applications:

• Memory in computing devices and embedded systems
• Video memory in graphics cards and display units
• Cache memory within processor-based systems
• Digital signal processing (DSP)
• Network devices

Features:

• Organization: 262,144 words × 4 bits
• Access Time: 60 ns
• Power Supply Voltage: 5V
• Package: TSOP (Thin Small Outline Package)
• Refresh: Self Refresh
• Low Power Consumption

Benefits:

• High-Speed Access: The 60 ns access time facilitates rapid data retrieval and storage, which is crucial for real-time applications.
• Sufficient Storage Capacity: The 262,144 words x 4 bits configuration provides adequate memory for various needs.
• Reduced Power Consumption: Minimizes energy usage, making it well-suited for battery-operated and power-sensitive devices.
• Simplified Integration: The TSOP package simplifies the board assembly process and reduces manufacturing costs.
• Reliable Operation: Engineered for stable and consistent performance, ensuring data integrity and system dependability.

Technical Specifications:

The MSM514265E-60T3-K operates on a 5V power supply and features low power consumption. It employs multiplexed address inputs, reducing the required number of address pins. It includes a refresh mechanism for data retention, typically a self-refresh mode for minimal power consumption during standby. The device is packaged in a standard TSOP, suitable for surface mount technology. Its typical operating temperature range is from 0°C to 70°C.

Manufactured using advanced CMOS technology, this DRAM delivers low power consumption and reliable performance. It is commonly employed in older computer systems, embedded controllers, and other applications that demand a balance of speed and memory capacity. This part provides a cost-effective solution for applications that need fast temporary storage.

In summary, the MSM514265E-60T3-K is a reliable and efficient DRAM, ideal for applications requiring rapid data access and moderate memory capacity. Its low power consumption and easy integration make it a versatile component for numerous electronic systems.
