The 3296W-103 is a multi-turn trimming potentiometer, commonly used for precise circuit adjustments. It's offered by several manufacturers, including OEN India Limited. The "103" designation indicates a resistance value of 10 kΩ (10 x 10^3 ohms).

Applications

• Calibration Circuits: Used to fine-tune the output of sensors, amplifiers, and other analog circuits.
• Voltage Adjustment: Employed to adjust voltage levels in power supplies, voltage regulators, and other circuits.
• Current Adjustment: Used to set current limits in power supplies and other circuits.
• Frequency Adjustment: Used in oscillators and filters to adjust the operating frequency.
• Gain Adjustment: Used in amplifiers to adjust the gain.

Features

• Multi-Turn Adjustment: Allows for precise and repeatable adjustments.
• Sealed Construction: Protects the potentiometer from dust, moisture, and other environmental factors.
• High Stability: Maintains its resistance value over time and temperature.
• Wide Resistance Range: Available in a wide range of resistance values to suit different applications.
• Through-Hole Mounting: Designed for easy mounting on printed circuit boards.
• Compact Size: Allows for use in space-constrained applications.

Benefits

• Precise Adjustment: Multi-turn design allows for fine-tuning of circuit parameters.
• Reliable Performance: Sealed construction and high stability ensure long-term reliable performance.
• Easy to Use: Through-hole mounting simplifies assembly.
• Versatile: Can be used in a wide range of applications.
• Stable Resistance: Resistance remains consistent under varying environmental conditions, ensuring circuit accuracy.
• Durable Construction: Robust design withstands mechanical stress and vibration.

Additional Details

The 3296W-103 typically has a power rating of 0.5W or less. Its operating temperature range is typically from -55°C to +125°C. The resistance tolerance is typically ±10%. The mechanical life is typically 200 cycles. The specific datasheet should be consulted for detailed electrical characteristics and application guidelines.

Overall the 3296W-103 trimming potentiometer is a versatile, reliable component for applications requiring precise circuit adjustments.
