Product Overview: NXP TJA1055T/3/C,518

The NXP TJA1055T/3/C,518 is a high-speed CAN transceiver that serves as an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. This transceiver is designed for automotive and industrial applications where reliable data communication is essential, such as in-vehicle networks, diagnostics, and module communications.

Key Features

• High-Speed CAN Interface: Supports the ISO 11898 standard for high-speed CAN applications, ensuring compatibility with up to 1 Mbit/s communication speeds.
• Low Power Mode: Features a very low-current Standby mode with bus wake-up capability, which is essential for power-sensitive applications.
• Transmit Data (TXD) Dominant Timeout: Prevents bus line damage due to prolonged transmission of dominant bits caused by TXD stuck low faults.
• Thermal Protection: Incorporated thermal protection disables the transmitter in the event of excessive temperature, ensuring the device's reliability and longevity.
• Bus Pins Protection: The bus pins are protected against transients in the automotive environment, providing robustness against electrical disturbances.

Applications

With its robust design and advanced features, the TJA1055T/3/C,518 is suitable for a wide range of applications, including:

• Automotive networks such as body control modules, gateway modules, and powertrain systems
• Industrial automation and control systems
• Marine electronics and onboard communication systems
• Medical equipment requiring reliable data transmission

Quality and Reliability

The TJA1055T/3/C,518 is manufactured by NXP, a trusted leader in automotive semiconductor solutions. It is available in an SO14 package and is characterized for operation over a wide temperature range of -40°C to +125°C, making it suitable for harsh environments. NXP's commitment to quality ensures that this transceiver meets the rigorous demands of automotive and industrial applications.

Ordering Information

The product is available with the orderable part number TJA1055T/3/C,518. For detailed information on pricing, availability, and ordering, please refer to NXP's official website or contact authorized distributors.
