NXP TJA1043T/1J High-Speed CAN Transceiver

The NXP TJA1043T/1J is a high-performance, standalone High-Speed Controller Area Network (CAN) transceiver that serves as an interface between a CAN protocol controller and the physical two-wire CAN bus. Designed to provide differential transmit and receive capability to (micro)controllers with CAN protocol support, it is an essential component for automotive and industrial applications that require robust communication with high immunity to electromagnetic interference.

Key Features

• ISO 11898-2:2016 Compliant: Ensures compatibility with the latest CAN standards for data transmission rates up to 1 Mbit/s.
• Low Power Modes: Features several low-power modes, including a Standby mode with bus wake-up capability and a Sleep mode, to reduce power consumption when the network is idle.
• Bus Fault Protection: Equipped with extensive bus fault protection against transients, ensuring reliable operation in a harsh electrical environment.
• Improved EMC Performance: Offers excellent Electromagnetic Compatibility (EMC) performance, including ESD protection, making it suitable for use in environments with high electromagnetic disturbances.
• Fail-Safe Features: Includes fail-safe features such as an undervoltage detection and a thermal protection circuit, enhancing system safety and reliability.

Applications

The TJA1043T/1J transceiver is designed for use in a variety of applications where CAN communication is required, including:

• Automotive networks
• Industrial control systems
• Building automation
• Medical equipment
• Heavy machinery

Technical Specifications

The TJA1043T/1J from NXP is a robust, high-speed CAN transceiver that ensures reliable communication in demanding applications. With its advanced features and compliance with the latest CAN standards, it is a top choice for designers looking to implement CAN networks in their systems.
