NXP MC9S08PT60AVLC Microcontroller

The NXP MC9S08PT60AVLC is a versatile and powerful microcontroller designed to cater to a wide range of applications, particularly in the automotive and industrial sectors. This 8-bit MCU is built on the HCS08 core and is part of the S08 family of microcontrollers known for their robustness and efficiency.

Key Features:

• CPU Speed: The MC9S08PT60AVLC operates at a frequency of up to 20 MHz, providing a balanced combination of processing power and power consumption for various applications.
• Flash Memory: Equipped with 60KB of on-chip flash memory, this microcontroller offers ample space for program storage and ensures reliable operation with its read/program/erase over the full operating voltage and temperature range.
• RAM: With 4KB of RAM, it provides sufficient space for data manipulation and temporary storage, facilitating efficient task handling.
• I/O Pins: It features 51 general-purpose input/output (GPIO) pins, allowing for versatile interfacing with a wide array of peripherals and components.
• Timers: Multiple timing systems including an 8-channel, 16-bit timer/pulse-width modulator (TPM) provide precise timing control for various tasks.
• Analog-to-Digital Converter: An integrated 12-channel, 12-bit analog-to-digital converter (ADC) enables the MCU to process analog signals, making it suitable for sensor interfacing and data acquisition.
• Communication Interfaces: The microcontroller supports various communication protocols such as I2C, SPI, and SCI, ensuring easy connectivity and data exchange with other devices.
• Operating Voltage: It operates within a range of 2.7V to 5.5V, providing flexibility in power supply design.
• Temperature Range: The device is operational over an extended temperature range from -40°C to +105°C, making it reliable in harsh environments.

Applications:

The MC9S08PT60AVLC is particularly suited for automotive control systems, including body electronics, sensors, and actuator controls. Its robust feature set also makes it an excellent choice for industrial control applications, home appliances, and consumer electronics where reliability and performance are paramount.

Package and Quality:

This microcontroller is offered in a 64-LQFP (Low Profile Quad Flat Package) which is designed for space-constrained applications. Additionally, it meets the stringent quality standards required for automotive and industrial applications, ensuring long-term reliability and performance.

With its comprehensive feature set and robust design, the NXP MC9S08PT60AVLC microcontroller stands as a solid choice for designers seeking a high-performance and adaptable MCU solution.
