NXP LPC2136FBD64/01 Microcontroller Overview

The NXP LPC2136FBD64/01 is a robust microcontroller designed for embedded applications requiring a high-performance yet cost-effective solution. This microcontroller is part of the widely acclaimed LPC2100 family, which is based on a 16/32-bit ARM7TDMI-S CPU with real-time emulation and embedded trace support that combines the high performance of an ARM core with the functionality and ease of use of NXP's peripheral interfaces.

The LPC2136FBD64/01 comes with 256 KB of on-chip Flash memory, providing ample space for most applications, and 16 KB of SRAM, ensuring smooth operation and data handling. It operates with a frequency of up to 60 MHz, which gives it the computational power to handle complex algorithms and tasks efficiently.

This microcontroller is designed with versatility in mind, featuring multiple 32-bit timers, an improved Vectored Interrupt Controller (VIC), an integrated 10-bit ADC, and multiple serial communication interfaces such as UART, SPI, and I2C. These features make it ideal for industrial control, medical systems, access control, and point-of-sale applications.

The LPC2136FBD64/01 also boasts a robust set of system control functions including a PLL for CPU clock generation, a Power Control module for power optimization, and a versatile Pin Connect Block for signal multiplexing and pin configuration. The inclusion of an In-System Programming (ISP) and In-Application Programming (IAP) capability means that the flash memory can be updated with new firmware while the microcontroller is installed in the end product, providing a flexible and convenient method for firmware upgrades.

The package type for this microcontroller is a low-profile 64-pin LQFP, which is ideal for space-constrained applications. The LPC2136FBD64/01 operates at a voltage range of 3.0V to 3.6V, striking a balance between power efficiency and signal integrity.

Overall, the NXP LPC2136FBD64/01 is a powerful and reliable microcontroller that offers a rich set of features and a high level of integration to meet the requirements of a wide range of applications. Its combination of processing power, memory capacity, and extensive peripheral set ensures that it remains a popular choice for designers looking for a scalable and flexible microcontroller solution.
