The NXP KMA220J is a high-precision dual magnetic rotary encoder designed for versatile positioning and speed sensing applications. This advanced sensor is built upon NXP’s innovative magnetic sensing technology, offering robust and reliable performance even in the most demanding environments.
Key Features
- Integrated Magneto-Resistive Sensors: The KMA220J features two magneto-resistive sensors that provide accurate angular position measurement with a wide range of magnetic field strengths.
- Programmable Angular Range: Users can program the angular range from 0 to 360 degrees, allowing for customization to specific application requirements.
- High Resolution: The device delivers high-resolution output, ensuring precise readings for critical applications.
- Temperature Compensation: The KMA220J includes built-in temperature compensation, maintaining accuracy across a broad temperature range.
- Digital Signal Processing: With advanced digital signal processing, the encoder provides clean, reliable outputs that are immune to electrical noise.
Applications
The NXP KMA220J is ideal for a variety of applications where precise motion sensing is required, including:
- Automotive steering and pedal position sensing
- Industrial motor control and robotics
- Consumer electronics
- Medical equipment
Technical Specifications
Parameter
Specification
Supply Voltage
4.5V to 5.5V
Output Signal
Digital PWM
Operating Temperature Range
-40°C to +125°C
Package
SOT-23
With its combination of durability, precision, and flexibility, the NXP KMA220J is a top choice for engineers and designers who require a reliable sensor for their sophisticated control systems.
