Products specifications

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) (per Diode) 200mA (DC)
Voltage - Forward (Vf) (Max) @ If 550mV @ 200mA
Current - Reverse Leakage @ Vr 15μA @ 30V
Operating Temperature - Junction 125°C (Max)
Mounting SMD (SMT)
Case / Package TO-236AB (SOT23)
Win Source Part Number 231703-BAT721C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name BAT721C
Introduction Date January 21, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian BAT721C CAD Model

Description

The NXP BAT721C is a high-performance Schottky barrier diode designed for applications requiring fast switching and low forward voltage drop. This diode is encapsulated in a compact SOT-23 package, making it suitable for high-density circuit board designs.

Key Features

  • Low Forward Voltage: The BAT721C offers a very low forward voltage drop, which enhances system efficiency by reducing power loss during operation.
  • Fast Switching Speed: With its fast switching capability, this diode is ideal for high-frequency applications, providing improved performance in circuits such as DC-DC converters, and high-efficiency power supplies.
  • High Surge Current Capability: It can handle high surge currents, making it robust in applications where transient current spikes are common.
  • Low Capacitance: The device has a low diode capacitance, which is beneficial for high-speed switching and reduces noise in RF applications.
  • Surface-Mount Package: The SOT-23 package is designed for surface-mount technology, allowing for automated assembly processes and space-saving PCB design.

Applications

The BAT721C is versatile and can be used in a variety of electronic circuits. Some common applications include:

  • Switching power supplies
  • DC-DC converters
  • Reverse polarity protection
  • Power management systems
  • Automotive applications
  • High-frequency rectification

Reliability and Quality

NXP Semiconductors is known for its commitment to quality and reliability. The BAT721C is manufactured with stringent quality control processes, ensuring high reliability and performance consistency for critical applications. It is RoHS compliant and lead-free, making it suitable for use in environmentally sensitive applications.

Technical Specifications

Parameter Value Package SOT-23 Peak Repetitive Reverse Voltage 30 V Average Rectified Forward Current 200 mA Non-Repetitive Peak Forward Surge Current 600 mA Forward Voltage Drop 0.385 V at 200 mA Operating Temperature Range -65°C to +125°C

In conclusion, the NXP BAT721C Schottky barrier diode is a reliable and efficient choice for designers looking for a component that offers fast switching, low forward voltage, and a compact footprint for their electronic designs.
