Manufacturer NXP
Win Source Part Number 1151487-BAT120C
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BAT120C CAD Model

Description

The BAT120C is a state-of-the-art Schottky barrier diode designed and manufactured by NXP Semiconductors, a leader in the industry known for its high-quality electronic components. This diode is engineered to offer superior performance in a variety of applications, making it an ideal choice for designers looking to enhance the efficiency and reliability of their electronic circuits.

Key Features

  • Low Forward Voltage Drop: The BAT120C boasts a low forward voltage drop, which translates to reduced power loss and improved energy efficiency in applications where it is used.
  • High Surge Current Capability: This diode is capable of handling high surge currents, ensuring robust performance and protection against unexpected current spikes.
  • Fast Switching Speed: With its fast switching capability, the BAT120C is suitable for high-frequency applications, providing quick response times and minimizing energy losses.
  • Low Capacitance: The low capacitance of this diode makes it an excellent choice for high-speed circuits, where it helps to maintain signal integrity and reduces noise.

Applications

The versatility of the BAT120C allows it to be used in a wide range of applications, including:

  • Switching power supplies
  • DC-DC converters
  • Free-wheeling diodes in power circuits
  • Reverse battery protection
  • Charge and discharge protection for battery-operated systems

Specifications

Parameter Value Package SOD-123 Repetitive Peak Reverse Voltage (V<sub>RRM) 100 V Average Forward Current (I<sub>F(AV)) 1 A Non-Repetitive Peak Forward Surge Current (I<sub>FSM) 25 A Operating Junction Temperature Range -40°C to +125°C

With its advanced features and robust design, the BAT120C from NXP Semiconductors is an excellent choice for any application requiring a high-performance Schottky barrier diode. Its reliability and efficiency make it a valuable component in the design and development of modern electronic systems.
