The NXP 74LVT16245BDGG is a high-performance, low-voltage BiCMOS device that is part of the LVT family, which stands for Low Voltage Technology. This integrated circuit is designed to address the needs for high-speed data transfer and signal integrity in a wide array of digital applications. It is particularly suitable for interfacing with 3.3V and 5V systems, making it a versatile choice for mixed-voltage environments.

Key Features

• Bi-directional Interface: This device features a 16-bit transceiver with bi-directional data flow, which allows for flexible data exchange between buses.
• Low Voltage Operation: It operates at a nominal voltage of 3.3V, which can help reduce power consumption and is compatible with 5V tolerant inputs.
• High-Speed Performance: Capable of supporting data transfer speeds that are consistent with the high demands of modern digital systems.
• Bus-Hold Data Inputs: The inputs include a bus-hold feature, which eliminates the need for external pull-up or pull-down resistors and ensures a stable state when inputs are left floating.
• Output Disable Feature: Outputs can be placed in a high-impedance state, which is essential for shared data lines and preventing bus contention.
• Live Insertion and Extraction: Designed to support live insertion and extraction without causing glitches or disruptions on the bus lines.

Applications

The 74LVT16245BDGG is ideal for use in a diverse range of applications, including telecommunications, computing, and industrial systems where reliable and fast data transfer is critical. Its ability to interface seamlessly between different voltage domains also makes it a popular choice for system upgrades and mixed-voltage system designs.

Package Information

The device is offered in a 48-pin TSSOP (Thin Shrink Small Outline Package) type, denoted by the 'BDGG' suffix in the part number. This package is optimized for reduced space on PCBs and enhanced thermal performance, ensuring reliable operation even in space-constrained applications.
