The 74HCT1G08GW from NXP Semiconductors is a high-speed Si-gate CMOS device that embodies the cutting-edge of logic gate technology. This single 2-input AND gate is part of the 74HCT family, which is known for its compatibility with TTL levels while maintaining the low power consumption of CMOS technology. This product is particularly designed for robust performance and is housed in a compact SOT-353 (SC-88A) surface-mount package, making it ideal for space-constrained applications.

Key Features

• Logic Type: 2-Input AND Gate
• Supply Voltage Range: 4.5V to 5.5V
• High-Speed Performance: t<sub>PD 8 ns (typ) at V<sub>CC 5V
• Low Power Consumption: 20 μA (max) at 25°C
• Output Capability: Standard
• Inputs Compatible with TTL Levels: Allows for easy integration with existing TTL systems
• ESD Protection: HBM JESD22-A114E exceeds 2000V
• Package: SOT-353 (SC-88A)
• Temperature Range: -40°C to +125°C

Applications

The 74HCT1G08GW is suitable for a wide range of applications, including:

• Function generators
• Logic level shifting
• Address decoding
• Control systems
• Embedded systems
• Telecommunications

Quality and Reliability

NXP Semiconductors is committed to the highest standards of quality and reliability. The 74HCT1G08GW is subjected to rigorous testing and quality control procedures, ensuring that it meets the stringent requirements of the industrial and commercial markets. With its robust design and proven performance, this AND gate is a reliable choice for critical logic functions in a variety of electronic circuits.

Ordering Information

For ordering the 74HCT1G08GW, or to request samples and additional product information, customers can visit the NXP Semiconductors official website or contact authorized distributors. Ensure that you are getting genuine NXP products by purchasing through official channels.
