The 74HCT08D is a high-speed Si-gate CMOS device from NXP Semiconductors, renowned for its robust performance and reliability. It is part of the 74HCT family, which is compatible with TTL levels and designed to operate at the same speed as low power Schottky TTL (LSTTL). The 74HCT08D is a quad 2-input AND gate IC, encapsulated in a sleek SO14 (Small Outline) package, making it a compact and efficient solution for a wide range of digital applications.

Key Features

• Logic Type: Quad 2-Input AND Gate
• Package Type: SO14
• Supply Voltage Range: 4.5V to 5.5V
• Operating Temperature: -40°C to +125°C
• Compatibility: TTL input levels
• Output Capability: Standard
• Propagation Delay: Typically 8ns at 4.5V, 20°C

Applications

The 74HCT08D is suitable for a myriad of digital circuits and can be utilized in various applications such as:

• Logic and computing devices
• Data processing units
• Embedded systems
• Control systems
• Signal gating

Quality and Reliability

NXP Semiconductors ensures that each 74HCT08D device meets the highest quality and reliability standards. The product undergoes rigorous testing and verification processes to guarantee optimal performance in demanding environments. Furthermore, the 74HCT08D is RoHS compliant, reflecting NXP's commitment to environmental sustainability and safety.

Technical Support and Resources

For engineers and designers, NXP provides extensive technical support, including datasheets, application notes, and design resources for the 74HCT08D. This support ensures seamless integration of the device into your projects, with NXP's expertise readily available to address any technical queries.
