Product Overview: 74HC4067BQ from NXP

The 74HC4067BQ is a high-performance, silicon-gate CMOS device from NXP Semiconductors, which features a 16-channel analog multiplexer/demultiplexer with a wide range of applications. This versatile component is designed to handle both digital and analog signals, making it an essential part of many electronic systems. The 74HC4067BQ boasts a robust design that can multiplex and demultiplex 16 different inputs/outputs to one common output/input.

Key Features

• Wide Voltage Range: It operates across a wide voltage range from 2.0V to 10V, providing flexibility in various power environments.
• Low ON Resistance: The device features low "on" resistance (70 Ω typical at V<sub>CC = 4.5V) which minimizes signal distortion and allows for the passage of high-quality signals.
• High Noise Immunity: Characterized by the inclusion of noise immunity and low power consumption, it is suitable for robust designs where signal integrity is paramount.
• Binary Address Decoding: It includes binary address decoding on the chip which simplifies the design and reduces the number of components required for operation.
• Break-before-make Switching: The 74HC4067BQ ensures break-before-make switching, preventing momentary shorting when switching between channels.

Applications

The 74HC4067BQ is ideal for use in a variety of applications including:

• Analog multiplexing and demultiplexing
• Signal gating
• Data routing
• Channel selection in data acquisition systems
• Communication systems
• Computer peripherals

Package and Quality

The device is available in a DHVQFN24 package, which is designed for space-constrained applications. The 74HC4067BQ is also supported by NXP's commitment to quality and reliability, ensuring that it meets the stringent requirements of industrial and commercial applications.

With its combination of features, the 74HC4067BQ from NXP stands out as a reliable and efficient solution for designers looking to manage multiple signal paths in their electronic designs. Its wide operating voltage range and low power consumption make it suitable for battery-operated devices, while its high noise immunity ensures reliable performance in noisy environments.
