Product Overview: 74HC04D

The 74HC04D is a high-speed Si-gate CMOS device and is pin compatible with low-power Schottky TTL (LSTTL). Manufactured by NXP, a leading semiconductor company, this integrated circuit is part of the 74HC family, which is recognized for its robust performance and widespread use in digital electronics.

Key Features:

• Hex Inverters: The 74HC04D contains six independent inverters, making it a versatile component for implementing logic functions in a variety of digital applications.
• High Noise Immunity: The inherent design of CMOS technology provides a high noise immunity, ensuring stable operation even in electrically noisy environments.
• Low Power Consumption: With CMOS technology, the 74HC04D benefits from low power dissipation, which is crucial for battery-operated and power-sensitive devices.
• Wide Operating Voltage Range: It operates over a wide voltage range of 2.0 to 6.0 V, accommodating various levels of signal voltages and system requirements.
• High-Speed Performance: The device is designed for high-speed operation, with typical propagation delays comparable to LSTTL counterparts.
• Standardized Symmetrical Output Characteristics: The outputs are symmetrical, which is essential for balanced propagation delays when driving capacitive loads.
• ESD Protection: The 74HC04D includes input and output protection against electrostatic discharge, enhancing the longevity and reliability of the device.

Applications:

The versatility of the 74HC04D makes it suitable for a wide array of applications, including:

• Logic inversion
• Oscillator circuits
• Wave shaping and signal processing
• Pulse generators
• Buffer circuits

Package Information:

The device is available in a SO14 (Small Outline Package) which is ideal for space-constrained applications. Its surface-mount design allows for efficient assembly in high-density PCB layouts.

Quality and Reliability:

NXP's commitment to quality ensures that the 74HC04D meets stringent industry standards for performance and reliability. Customers can trust the 74HC04D for their critical design requirements.
