The MS22BSG40 is a compact and robust toggle switch manufactured by NKK Switches, designed for demanding applications requiring reliable performance and long-lasting durability. It belongs to the MS series, known for its exceptional quality and versatile design.

Applications

• Industrial Control Panels: Used extensively in control panels for machinery and equipment, providing reliable on/off or mode selection.
• Test and Measurement Equipment: Employed in various testing and measurement instruments for precise control and signal routing.
• Telecommunications Equipment: Integrated into telecommunications devices for power switching and configuration settings.
• Medical Devices: Utilized in medical equipment requiring high reliability and consistent performance.
• Transportation Systems: Found in control systems for vehicles, trains, and aircraft, providing critical switching functions.

Features

• Miniature Size: Compact design allows for high-density mounting on printed circuit boards.
• Toggle Actuation: Offers a tactile and positive switching action, providing clear indication of switch position.
• High Contact Rating: Capable of handling substantial current and voltage loads, ensuring reliable performance in demanding applications.
• Sealed Construction: Designed to prevent the ingress of dust and moisture, enhancing reliability in harsh environments.
• Long Life Expectancy: Engineered for extended operational life, reducing the need for frequent replacements.
• Various Termination Options: Available with different termination styles to suit various mounting and wiring requirements.

Benefits

• Reliable Performance: Ensures consistent and dependable switching action in critical applications.
• Space-Saving Design: Allows for efficient use of board space in compact electronic devices.
• Enhanced Durability: Withstands harsh environmental conditions, ensuring long-term reliability.
• Easy Integration: Simplified mounting and wiring due to versatile termination options.
• Reduced Maintenance: Long life expectancy minimizes the need for frequent maintenance and replacements.
• Improved Safety: Positive switching action provides clear indication of switch position, enhancing operational safety.

Additional Details

The MS22BSG40 typically features a single-pole double-throw (SPDT) configuration, offering versatile switching capabilities. It is constructed with high-quality materials to ensure robustness and longevity. The switch body is often made from durable plastic, while the contacts are typically gold-plated to provide excellent conductivity and corrosion resistance. Electrical specifications include a voltage rating of up to 125VAC and a current rating of several amps. Operating temperature ranges from -25°C to +70°C. The specific dimensions and mounting details can be found in the product datasheet provided by NKK Switches.
