NJM3771FM2-TE3 NJR Corporation/NJRC NJM3771FM2-TE3 real image4049
Same model may have multiple batches, images only for reference.
NJM3771FM2-TE3 NJR Corporation/NJRC NJM3771FM2-TE3 real image4049
NJM3771FM2-TE3 NJR Corporation/NJRC NJM3771FM2-TE3 real image4049
Same model may have multiple batches, images only for reference.

NJM3771FM2-TE3

Part No NJM3771FM2-TE3
Manufacturer NJR Corporation/NJRC
Catalog PMIC - Motor Drivers, Controllers
Description Bipolar Motor Driver Bipolar Parallel 28-PLCC (11.51x11.51)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family PMIC - Motor Drivers, Controllers
Manufacturer NJR-Corporation-NJRC
Packaging Tube
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface Parallel
Technology Bipolar
Step Resolution 1, 1/2
Applications General Purpose
Current - Output 650mA
Operating Supply Voltage 4.75 V ~ 5.25 V
Voltage - Load 10 V ~ 40 V
Operating Temperature Range -20°C ~ 125°C (TJ)
Mounting Style SMD/SMT
Package 28-LCC (J-Lead)
Manufacturer Device Package 28-PLCC (11.51x11.51)
Win Source Part Number 003958-NJM3771FM2-TE3
Family Name NJM3771
Introduction Date March 31, 2000
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian NJM3771FM2-TE3 CAD Model

Description

The NJM3771FM2-TE3 is a fully integrated bipolar driver for bipolar stepper motors. It is designed for general purpose applications and operates on an operating supply voltage of 4.75 V to 5.25 V.

  • Output Configuration: Half bridge
  • Current Output: 650mA
  • Voltage Load: 10 V to 40 V
  • Step Resolution: 1, 1/2
  • Interface: Parallel
  • Package: 28-LCC (J-Lead)
  • Operating Temperature: -20°C to 125°C (TJ)
  • Manufacturer: NJR-Corporation-NJRC
  • EOL Date: 2019
