NJM2284M-TE1 NJR Corporation/NJRC
Same model may have multiple batches, images only for reference.

NJM2284M-TE1

Part No NJM2284M-TE1
Manufacturer Nisshinbo Micro Devices Inc.
Catalog Linear - Video Processing
Description IC VIDEO SWITCH 2IN/1OUT 16DMP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Linear - Video Processing
Mfr Nisshinbo Micro Devices Inc.
Package Tape & Reel
Product Status Obsolete
Function Video Switch, 2-Input 1-Output
Applications Consumer Video
Voltage - Supply 4.75V ~ 13V
Mounting Type Surface Mount
Package / Case 16-SOIC (0.197", 5.00mm Width)
Supplier Device Package 16-DMP
Standard Package 2,000 pcs
ECCN OBSOLETE
Win Source Part Number 254143-NJM2284M-TE1
Ultra Librarian 3D Model Ultra Librarian NJM2284M-TE1 CAD Model

Description

The NJM2284M-TE1 is an obsolete integrated circuit designed for video processing applications.

  • Function: It functions as a 2-input, 1-output video switch, allowing for seamless switching between video sources.
  • Voltage Supply: The NJM2284M-TE1 operates on a supply voltage range of 4.75V to 13V, providing a stable power source for video processing.
  • Package: It is housed in a 16-SOIC package and is designed for surface mount applications.
  • Status: Although this product is obsolete, it was widely used in consumer video applications due to its reliable performance.
  • Note: Please note that the NJM2284M-TE1 is no longer in production and may not be readily available in the market.
