The NPIM104B2R2MTRF is a power inductor manufactured by NIC-Components Corp. It is designed for use in a variety of power supply applications, offering a compact size and efficient performance. This inductor is particularly well-suited for applications requiring a small footprint and reliable operation in demanding environments.

Applications:

• DC-DC converters
• Power supplies for portable devices
• LED lighting
• Buck and boost converters
• Voltage regulators

Features:

• Shielded construction for low EMI
• High saturation current
• Compact size: 10.0 x 10.0 x 4.0 mm
• Surface mount design
• Operating temperature range: -40°C to +125°C
• High reliability

Benefits:

• Reduced electromagnetic interference (EMI), leading to cleaner power and less noise in sensitive circuits.
• Efficient power conversion due to low DC resistance, minimizing power loss and improving overall system efficiency.
• Space-saving design, allowing for miniaturization of electronic devices.
• Easy assembly using standard surface mount techniques, reducing manufacturing costs.
• Stable performance over a wide temperature range, ensuring reliable operation in various environments.

Technical Specifications:

Inductance: 2.2 µH
Tolerance: ±20%
Saturation Current: 3.5 A
DC Resistance (DCR): 32 mΩ (typical)
Self-Resonant Frequency (SRF): 50 MHz (typical)
Operating Temperature: -40°C to +125°C
Core Material: Ferrite
Termination: Tin plating

The shielded construction of the NPIM104B2R2MTRF minimizes electromagnetic interference (EMI), making it suitable for use in sensitive applications where noise reduction is crucial. Its high saturation current ensures stable performance even under high current conditions. This inductor's robust design and reliable performance make it a suitable choice for a wide range of power supply applications.
