BAV23A,215 Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

BAV23A,215

Part No BAV23A,215
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY GP 200V 225MA SOT23
Datasheet
BAV23A,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Nexperia USA Inc.
Package Tape & Reel
Product Status Active
Diode Configuration 1 Pair Common Anode
Technology Standard
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) (per Diode) 225mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.25 V @ 200 mA
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 100 nA @ 200 V
Operating Temperature - Junction 150°C (Max)
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package TO-236AB
Base Product Number BAV23
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 818796-BAV23A,215
Ultra Librarian 3D Model Ultra Librarian BAV23A,215 CAD Model

Description

The 818796-BAV23A,215 is a diode rectifier array from Nexperia USA Inc.

  • Maximum reverse voltage: 200V
  • Forward voltage: 1.25V @ 200mA
  • Recovery speed: < 500ns
  • Package: TO-236-3, SC-59, SOT-23-3
  • Temperature range: -40°C to 150°C
  • Standard package quantity: 3,000 pieces
