The 74HCT238BQ,115 is a high-speed Si-gate CMOS device from Nexperia, featuring a 3-to-8 line decoder/demultiplexer. This device is suitable for memory address decoding or data routing applications. The HCT family is characterized by its high-speed performance and CMOS low power dissipation.

Applications

• Memory address decoding
• Data routing
• Address decoding in microprocessor systems
• Logic control systems
• Industrial automation

Features

• 3-to-8 line decoding/demultiplexing
• CMOS technology for low power consumption
• High-speed operation
• Output enable inputs for easy expansion
• Complies with JEDEC standard no. 7A

Benefits

• Simplifies memory addressing schemes
• Reduces power consumption in battery-powered applications
• Enhances system performance with fast decoding speeds
• Allows for larger memory maps through expansion
• Ensures compatibility with other logic devices

Additional Details

The 74HCT238BQ,115 operates within a supply voltage range of 4.5V to 5.5V. It is available in a DHVQFN16 (very thin quad flatpack no leads) package. The device features three binary select inputs (A0, A1, A2) and three enable inputs (E1, E2, E3). When all enable inputs are active (LOW), the device decodes the binary address present on the select inputs and activates the corresponding output. Unselected outputs are HIGH. The device's inputs include clamp diodes, enabling the use of current limiting resistors to interface inputs to voltages in excess of VCC.
