NHD-C0220BIZ-FS(RGB)-FBW-3VM

Part No NHD-C0220BIZ-FS(RGB)-FBW-3VM
Manufacturer Newhaven
Catalog Display Modules - LCD, OLED Character and Numeric
Description LCD MOD 40DIG 20X2 TRANSFL R/G/B
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Characters 40.0
Display Format 20 x 2
Character Format 5 x 8 Dots
Display Type FSTN - Film Super-Twisted Nematic
Display Mode Transflective
Character Size 5.55mm H x 2.45mm W
Outline L x W x H 75.70mm x 27.10mm x 6.80mm
Viewing Area 61.00mm L x 15.10mm W
Backlight LED - Red/Green/Blue
Voltage - Supply 2.7V ~ 3.5V
Dot Size 0.45mm W x 0.65mm H
Interface I2C
Controller Type ST7036
Temperature Range - Operating -20°C ~ 70°C
Text Color Black
Background Color Red/Green/Blue
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1565415-NHD-C0220BIZ-FS(RGB)-FBW-3VM
Ultra Librarian 3D Model Ultra Librarian NHD-C0220BIZ-FS(RGB)-FBW-3VM CAD Model
