NTA0505MC-R Real Image NTA0505MC-R Real Image1 NTA0505MC-R Real Image2
Same model may have multiple batches, images only for reference.
NTA0505MC-R Real Image NTA0505MC-R Real Image1 NTA0505MC-R Real Image2
NTA0505MC-R Real Image NTA0505MC-R Real Image1 NTA0505MC-R Real Image2
Same model may have multiple batches, images only for reference.

NTA0505MC-R

Part No NTA0505MC-R
Manufacturer Murata Power Solutions Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description CONV DC/DC SM 1W 5VIN 5V DL 1KV / Module DC-DC 5VIN 2-OUT 5V/-5V 0.1A/-0.1A 1W 10-Pin SMD T/R
Datasheet
NTA0505MC-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Murata Power Solutions Inc.
Series NTA
Packaging Reel package
Type Isolated Module
Number of Outputs 2
Input Voltage MIN 4.5V
Voltage Input MAX 5.5V
Voltage - Output 1 5V
Voltage - Output 2 -5V
Current - Output (Maximum) 100mA, 100mA
Power (Watts) 1W
Voltage - Isolation 1kV (1000V)
Applications ITE (Commercial)
Operating Temperature Range -40°C ~ 85°C
Efficiency 69%
Mounting SMD
Package 18-SMD Module, 10 Leads
Dimension 0.60" L x 0.30" W x 0.26" H (15.2mm x 7.6mm x 6.6mm)
Win Source Part Number 790835-NTA0505MC-R
Popularity Medium
Supply and Demand Status Limited
Family Name NTA0505
Introduction Date June 27, 2007
Country of Origin China
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian NTA0505MC-R CAD Model

Description

The Murata Power Solutions Inc. NTA0505MC-R is a 1W Isolated Module with 2 outputs.

  • Operating Temperature: -40°C to 85°C
  • Voltage Isolation: 1kV (1000V)
  • Package: 18-SMD module, 10 leads
  • Application: ITE (Commercial)
  • Dimension: 0.60" L x 0.30" W x 0.26" H (15.2mm x 7.6mm x 6.6mm)
  • Efficiency: 69%
  • Voltage Output 1: 5V
  • Voltage Output 2: -5V
  • Input Voltage Range: 4.5V to 5.5V
  • Current Output: 100mA (Both Outputs)
  • Series: NTA
  • Category: Power Supplies - Board Mount
