BWR-12/125-D12-C Real Image
Same model may have multiple batches, images only for reference.

BWR-12/125-D12-C

Part No BWR-12/125-D12-C
Manufacturer Murata Power Solutions Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-12V 3W / Isolated Module DC DC Converter 2 Output 12V -12V 125mA, 125mA 9V - 18V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Manufacturer Murata Power Solutions Inc.
Packaging Tube
Product Status Not For New Designs
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 9V
Voltage - Input (Max) 18V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 125mA, 125mA
Power (Watts) 3 W
Voltage - Isolation 1 kV
Applications ITE (Commercial)
Features OCP, OVP
Temperature Range - Operating -25°C ~ 75°C
Efficiency 75%
Mounting Through Hole
Case / Package 8-DIP Module
Size / Dimension 1.25" L x 0.80" W x 0.45" H (31.8mm x 20.3mm x 11.4mm)
Base Product Number BWR-12
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Standard Package 14
Win Source Part Number 1335117-BWR-12/125-D12-C
Ultra Librarian 3D Model Ultra Librarian BWR-12/125-D12-C CAD Model

Description

The Murata Power Solutions Inc. BWR-12/125-D12-C is an isolated module DC-DC converter that is designed for use in ITE (Commercial) applications.

  • Applications: ITE (Commercial)
  • Protection: OCP and OVP protection
  • Power Output: 3W
  • Outputs: Two outputs
  • Maximum Output Current: 125mA each
  • Input Voltage Range: 9V to 18V
  • Output Voltage: 12V (first output), -12V (second output)
  • Package: 8-DIP module package
  • Size: 1.25" L x 0.80" W x 0.45" H (31.8mm x 20.3mm x 11.4mm)
  • Efficiency: 75%
  • Isolation Voltage: 1 kV
