78602/3JC-R Real Image
Same model may have multiple batches, images only for reference.

78602/3JC-R

Part No 78602/3JC-R
Manufacturer Murata Power Solutions Inc.
Catalog Pulse Transformers
Description TRANSFORMER
Datasheet
78602/3JC-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Murata Power Solutions Inc.
Series *
Dimension 0.354" L x 0.375" W (9.00mm x 9.52mm)
Height - Seated (Maximum) 0.250" (6.35mm)
Win Source Part Number 766181-78602/3JC-R
Popularity Medium
Supply and Demand Status Limited
Family Name 786J
Introduction Date January 01, 2000
ECCN EAR99
Country of Origin China
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian 78602/3JC-R CAD Model

Description

The Murata Power Solutions Inc. transformer is a high-quality component.

  • Series: 786J
  • Dimension: 0.354" L x 0.375" W (9.00mm x 9.52mm)
  • Height (Seated): 0.250" (6.35mm)
  • Country of Origin: China
  • EOL Date: 2028 (Estimated)
  • Popularity: Medium
  • Supply and Demand Status: Limited
